Item
19 Engine Regen Initiate/Inhibit Switch (ISX only)
20 Swing Horn Button
21 Skylight Wiper Switch; Skylight Wiper
22 Swing Brake Pedal
23 Cab Circulating Fan
24 Operator Display
25 360° Swing Lock Control (Positive Lock Type)
26 12V Accessory Outlet
27 RCL Override Switch
28 Emergency Stop Switch
29 Jib Stowage Controller
30 RCL Panel
31 Engine Increment/Decrement Switch
32 Ignition Switch
33 Air Conditioner Switch (Optional)
34 Heater/Air Conditioner Control Switch
35 Hoist Rotation Indicator (Main and Aux Hoist)
36 Heater/Air Conditioner Fan Switch
37 Crane Function Power Switch
38 Windshield Wiper/Washer Switch
39 Swing Joystick
40 Work Lights Switch
41 Boom Lights Switch (Optional)
42 Swing Speed Switch
Crane System Diagnostic Connector (Not
43
Shown)
Swing Speed Switch
The swing speed switch (42) is a two-position switch located
on the left armrest. Push the top of the switch for high swing
speed or the bottom of the switch for low swing speed.
Cab Tilt Switch
The cab tilt switch (11) is located on the right armrest. It is a
three position, momentary spring centered to off rocker
switch. The switch allows the cab to be tilted either up or
down.
Jib Stowage Controller
The remote jib stowage controller (29) is stored behind the
seat in the superstructure cab. The IN and OUT switch on
the controller is used to pivot the jib during erecting and
GROVE
Description
Published 02-06-2014, Control # 495-00
OPERATING CONTROLS AND PROCEDURES
stowing procedure. Refer to "Set-up and Installation" on
page 4-1.

Accessory Controls and Indicators

Work Lights Switch
The work lights switch (40) is a two position ON/OFF switch
located on the overhead console, it controls the crane's work
lights (1) mounted on the bottom front of the superstructure
cab. Press the top of the switch to the on position to
illuminate the work lights. Press the bottom of the switch to
turn the work lights off.
Boom Lights Switch (Optional)
The boom lights switch (41) is a two position ON/OFF switch
located on the overhead console. The switch controls the
flood lights located on the boom base section. Press the top
of the switch to the ON position to illuminate the flood lights.
Press the bottom of the switch to turn the flood lights off.
Cab Circulating Fan
The cab circulating fan (23) is located on the right side of the
cab. A swivel allows the fan to be positioned in any direction
and a HIGH-OFF-LOW switch on the base controls the fan.
Cab Dome Light
The cab dome light (12) is located on the right rear corner of
the cab roof and provides illumination of the cab. The light is
controlled by an ON/OFF switch on the light.
Fire Extinguisher
The fire extinguisher (15) is located at the left rear side of the
cab. The fire extinguisher is a BC rated dry type fire
extinguisher for emergency use.
Windshield Wiper/Washer Switch and Motor
The windshield wiper/washer toggle switch (38) is located on
the right side of the overhead panel. The switch is used for
removing moisture from the windshield. The switch has an
OFF and HIGH position with six intermittent positions
between HIGH and OFF. Pushing the switch up from the
OFF position energizes the wiper motor (2). Continue to
push switch up for each intermittent position and the HIGH
position. Push the switch down to OFF to stop the motor and
return the wiper blade to the parked position.
Push the very top of the switch to activate the washer switch
to spray washer fluid on the windshield.
Skylight Wiper Switch
The skylight wiper switch (21) is installed on the overhead
console. The wiper is used to remove moisture from the
skylight. The switch has an OFF and HIGH position with six
intermittent positions between HIGH and OFF. Pushing the
switch up from the OFF position energizes the wiper motor.
