Manitowoc Grove TMS800E13 Operator's Manual page 154

LUBRICATION
Drain, fill, and replace filter every 80,000 km (50,000 mi)
or 2 years, whichever interval occurs first
Lube Amount - Capacity - 18.9 l (20 qt)
Application - Fill to check plug on the left-hand side of
the transmission.
4. Pump Drive Shaft
a. U-Joints
Lube Type - EP-MPG
Lube Interval - 250 hours
Lube Amount - Until grease extrudes
Application - 2 grease fittings
b. Spline
Lube Type - EP-MPG
Lube Interval - 500 hours
Lube Amount - Until grease extrudes
Application - 1 grease fitting
5. PTO Clutch
Lube Type - HYDO
Lube Interval - 500 hours or 3 months
Lube Amount - Capacity - 650 ml (22 fl.oz.)
Application - Fill until oil weeps from side port.
6. Driveline
Lube Type - EP-MPG
Lube Interval - 500 Hours or 10,000 miles whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 3 grease fittings
7. Power Steering Gearbox
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 1 grease fitting
8. Steering Relay Arms
Lube Type - EP-MPG
Lube Interval - 250 hours
Lube Amount - Until grease extrudes
Application - 2 grease fittings
6
9.
.
10. Front Axle Hubs
11. Front Axle Tie Rod Ends
12. Front Axle King Pins
13. Front Axle Brake Slack Adjusters
14. Front Axle Brake Camshafts
Published 02-06-2014, Control # 495-00
TMS800E13 OPERATOR MANUAL
Front Aluminum Wheel Pilots
Lube Type - ASC
Lube Interval - When wheels are removed for service.
Lube Amount - Generously coat the wheel pilot or hub
pads with anti-seize (ASC) compound. Do not apply
anti-seize compound to the face of the wheel of the hub.
Application - Brush on
CAUTION
Axle fluid levels shall be adjusted to bottom of fill plug
threads. Check with crane on level ground, at its normal
ride height, cold or room temperature oil only.
Lube Type - SSGL-5
Lube Interval - Check fluid level every 250 hours and
refill as necessary.
Lube Amount - 0.95 liter (1.0 quart)
Application - Fill to the oil level mark on the housing with
the fill plug and the oil level mark horizontal.
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 8 grease fittings
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
