Assembly Of Jibs - Manitowoc Grove TMS800E13 Operator's Manual

SET-UP AND INSTALLATION
The following sections are identified by the serial number:
- All parts of the 17.1 m (56 ft) bi-fold swingaway
lattice extension.
- Both sections of the 4.9 m (16 ft) sections.
.
CAUTION
Operate the crane only with those sections of the jib which
have the same serial number as the crane. This prevents
malfunctions and damage.
NOTE: For technical reasons a crane may only be set with
one jib.
If you wish to use the jib on several Manitowoc/Grove
cranes, the parts of the jib must be adjusted for these cranes
and labeled with all of the respective serial numbers.
CAUTION
Have the adjustment of the jib only carried out on site by
Manitowoc Crane Care.
28
Serial numbers on the 4.9 m (16 ft) sections
The serial number is on a plate at the front of the 4.9 m (16 ft)
sections.
Slinging Points
This section shows the slinging points of the 4.9 m (16 ft)
sections. Attach the sections only to these slinging points
because they will then automatically have the correct
center of gravity. Use only lifting gear with sufficient load
bearing capacity.
The 4.9 m (16 ft) sections have two slinging points (one
slightly offset on each side) (Figure 4-61).
NOTE:

ASSEMBLY OF JIBS

NOTE:
Published 02-06-2014, Control # 495-00
TMS800E13 OPERATOR MANUAL
CAUTION
For electrical connections at the 4.9 m (16 ft)
sections, refer to Electrical Connections at the Jib,
in this section.
The lengths of 22.0 m (72 ft) and 27.1 m (89 ft)
respectively equal the distance between the center
of the locking pin (on the main boom head) and the
front edge of the head sheave.
