LUBRICATION
27. Coolant Strainer (Superstructure Cab Heater)
Close the shutoff valves. Unscrew the hex plug and
clean the strainer screen after first 100 hours and every
2000 hours or 12 months thereafter.
28. N/A

SUPERSTRUCTURE LUBRICATION

29. Turntable Gear Box
Lube Type - SSGL-5
Lube Interval - Check and fill every 50 hours. Drain and
fill after first 250 hours and every 500 hours or 12
months thereafter, whichever interval occurs first.
Lube Amount -5.4 l (1.4 gal)
Application - Fill until oil level is at top of sight gauge
30. Turntable Gear and Drive Pinion
Lube Type - OGL
Lube Interval - 500 hours or 6 months, whichever
interval occurs first
Lube Amount - Coat all teeth
Application - Spray on; 2 places
Swivel Lock Pin
Lube Type - EP-OGL
Lube Interval - 500 hours or 6 months, whichever
interval occurs first
Lube Amount - Coat pin
Application - Spray on
31. Turntable Bearing
Lube Type - EP-MPG
Lube Interval - 500 hours or 6 months, whichever
interval occurs first
Lube Amount - Until grease extrudes the whole
circumference of the bearing.
Application - 2 grease fittings. Rotate the turntable 90°
and apply grease to fittings. Continue rotating 90° and
grease the fittings until the whole bearing is greased.
32. Main Hoist
Lube Type - AGMA EP-4
Lube Interval - Check and fill every 1000 hours or 12
months, whichever interval occurs first. Drain and fill
annually.
Lube Amount - Capacity - 14.7 l (15.5 qt)
Application - Fill until level with the check plug opening.
10
33. Auxiliary Hoist
BOOM, JIB, AND BOOM ACCESSORIES
LUBRICATION
NOTE:
34. Boom Pivot Shaft
35. Extend Cable Sheaves
36. Retract Cable Sheaves
Published 02-06-2014, Control # 495-00
TMS800E13 OPERATOR MANUAL
Lube Type - AGMA EP-4
Lube Interval - Check and fill every 1000 hours or 12
months, whichever interval occurs first. Drain and fill
annually.
Lube Amount - Capacity - 14.7 l (15.5 qt)
Application - Fill until level with the check plug opening.
To service the boom at boom lengths longer than
120 ft (to access grease fittings, grease the
sections, or to change the holding valve), a
minimum of 12,000 pounds of counterweight must
be installed on the turntable and the outriggers
must be fully extended. Boom must be positioned
over the right-hand side of the machine. No rigging,
no hook block, or overhaul ball may be installed on
the nose of the boom.
Extend boom to desired length at a boom angle of
20 degrees. Lower boom until RCL limits the boom
lower function. Override RCL per RCL Operator's
Manual and lower boom to desired angle.
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 2 grease fittings, one on each side
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 1 grease fitting; extend boom for entry
through access holes in fly and outer mid sections.
Lube Type - EP-MPG
Lube Interval - 250 hours or 3 months, whichever
interval occurs first
Lube Amount - Until grease extrudes
Application - 2 grease fittings; extend boom for entry
through access holes in front of inner mid section at
boom length of 39 m (128 feet)
