indicates road speed in both km/hr (kilometers per hour) and
mph (miles per hour).
Odometer
There is an odometer (16) located at the bottom of the
speedometer and shows total distance traveled.
Parking Brake Control
NOTE: The park brake must be set before the outrigger
controls will operate.
The parking brake control (12) is located on the right side of
the front console. The control is a push-pull type air valve
used to apply and release the parking brakes on all four rear
wheels.
Park Brake Engaged Indicator
The park brake engaged indicator (29) is located at the top of
the front console. The indicator illuminates red when the
GROVE
OPERATING CONTROLS AND PROCEDURES
crane parking brakes are applied. It is illuminated by a
pressure switch on the parking brake valve.
The bottom of the indicator (if equipped with a trailing boom)
illuminates red to warn the operator that the swing brake
release pressure is not enough to hold the swing brake
disengaged during trailing boom operation. In addition to
illuminating the indicator, a warning buzzer will sound.
Cross-Axle Differential Locked Indicator (Optional)
The cross-axle differential locked indicator (26) is located at
the left center side of the front console. The amber indicator
illuminates to show that the cross axle differential is locked.
Do not operate the cross axle differential lock or the inter-
axle differential lock on dry roads.
