TMS800E13 OPERATOR MANUAL
Crane Function Curve Response (6)
There is a correlation in the software between joystick/pedal
movement and how quickly the output is energized to meet
the input stimulation. This response time is present to
provide a smooth crane function regardless of how quickly
the input is increased. This preset has five different states
from a straight line (no modified response) increasing
exponentially to a sharp response time. As the curve
increases, the response time decreases.
Edit Currently Loaded Presets (7)
The operator will now be able to select a preset value(s) to
modify. The screen will transition to "Modify Presets Screen
2".
GROVE
OPERATING CONTROLS AND PROCEDURES
Reset Currently Loaded Presets (8)
The preset values will be set back to the default values: 0 for
threshold, 100 for max, and a flat line for the curve response.
The operator will need to press the save button in order for
the reset to be completed.
Save Currently Loaded Presets (9)
When this button is pressed all modified parameters will be
saved to their designated EEPROM locations. The screen
will transition to "Modify Presets Screen 4".
ESC (10)
Pressing the escape button at this point will return the
operator to the menu screen. If the save button was not
pressed prior to this button, any changes made to the
presets will be ignored.
Published 02-06-2014, Control # 495-00
3
3-21
