OPERATING CONTROLS AND PROCEDURES
Item
38 Throttle Pedal
39 Engine ECM Diagnostic Connector
40 Transmission Shift Lever
41 Ash Tray
42 Beacon Light (Optional)
43 Fire Extinguisher
44 Cab Dome Light (Not Shown)
45 Steering Wheel
46 Horn Button
Headlight Dimmer/Turn Signal Lever/Cruise
47
Control
48 Seat
49 Sun Visor
50 Cab Circulating Fan
51 Windshield Defroster Air Outlet
52 Heater Control Switch
53 Cab Marker Lights
54 Fuse and Relay Panel (Not Shown)
55 Hazard Light Switch
56 Steering Column Tilt/Telescope Lever
57 Emergency Stop Indicator
58 Regen Needed/Regen Inhibited Indicator
59 Diesel Exhaust Fluid Level Gauge (ISX Only)
Regenerate/Inhibit Regenerate Switch (ISX
60
Only)
High Exhaust System Temperature Indicator
61
(ISX Only)
62 Pump Engage/Disengage Switch (ISX Only)
63 Pump Engage Indicator (ISX Only)
64 Malfunction Indicator Lamp (ISX Only)
Crane System Diagnostic Connector (Not
65
Shown)
Cross-Axle Differential Lock Switch (Optional)
The cross-axle differential lock switch (17) is located on the
left center side of the front console and is used to lock the
right and left wheels in a tandem set. The cross-axle
differential lock increases traction on slippery roads. It is a
two position lock/unlock switch. Press top of switch for the
lock position or bottom of switch for the unlock position.
3-8
Description
Published 02-06-2014, Control # 495-00
TMS800E13 OPERATOR MANUAL
CAUTION
Do not operate cross-axle differential lock while crane
wheels are spinning or at speeds over approximately 16
km/h (10 mph). Release the throttle when locking or
unlocking.
Inter-Axle Differential Lock Switch
The inter-axle differential lock switch (15) is located on the
left center side of the front console. In the lock (press top of
switch) position, both rear axles are locked together and
turning at the same speed. In the unlocked (press bottom of
switch) position, the axles operate independently of each
other.
CAUTION
Do not operate inter-axle differential lock switch while
c r a n e w h e e l s a r e s p i n n i n g o r a t s p e e d s o v e r
approximately 16 km/h (10 mph). Release the throttle
when locking or unlocking.
Inter-Axle DIfferential Lock Indicator
The inter-axle differential lock indicator (32) is located on the
left center side of the front console. The amber indicator
illuminates when the inter-axle differential lock is engaged.
Brake Pedal
The brake pedal (37) is located on the cab floor, to the left of
the foot throttle and is used to apply the service brakes.
Transmission Shift Lever
The transmission shift lever (40) is located on the right side
of the cab. It is used to select the transmission gears. Refer
to "Shifting Gears" on page 3-54 in this section for complete
transmission operating instructions.
Trailing Boom Trailer Emergency Brake Control
(Optional)
The trailing boom (trailer emergency) brake control (11) is a
push-pull type air valve located on the right side of the front
console. The control is used to set and release the brakes
on the trailing boom trailer. Pull the control knob out to apply
and push control knob in to release the trailing boom trailer
brakes. If the air brake system pressure becomes low, the
Emergency Brake Control knob will automatically return to
the Emergency Brake "ON" position (control knob out).
Traveling without (Optional) Trailing Boom Trailer - If
Equipped
Traveling without the optional trailing boom trailer attached
and with the boom stowed in the carrier boom rest; the
carrier parking brakes (12) must be released (control knob
pushed in) and the trailing boom park brake control valve
