PortConfig

Use PortConfig to manage configuration of switch ports.
The following applies to SmartSwitch 6500 only: You can hot-swap TSMs.
Note
Hot-swapping is replacing a module when the chassis is powered up. If you
replace a TSM with another TSM of the same type (same I/O ports), existing
configuration of port parameters is not affected. This includes parameters set
using any of the following attributes: ATMRoute, CACServiceClassBw,
IlmiConfig, NetPrefix, Port, PortConfig, PVC, PVP, ServiceRegistry, SigTimer,
SigStatistics, SSCOPConfig, and SSCOPStatistics. If you replace a TSM with
another TSM of a different type, existing configuration of port parameters is
deleted. The deletion occurs when the new module is plugged into the chassis
backplane.
Operators
modify, show
Parameters
Input Parameter Description
[PortNumber] Port number on the switch. You can specify
a physical or virtual port.
[PortAdminStatus] Enables/disables administrative status of
the port. If the port is Down, it remains idle
with no activity ( such as signalling, ILMI,
or PVCs).
[IlmiAdminStatus] Enables/disables ILMI status of the port.
[SigType] Type of signalling on the port. autoConfig
means ILMI determines signalling type by
negotiation (hence ILMI cannot be
disabled for SigType autoConfig). pvcUni
and pvcNni disable signalling.
[SigRole] Signalling role.
[InterfaceType] Interface type.
[MaxVpiBits] Maximum number of VPI bits.
Value/Field Size
1A1 to 8B4 ( for physical ports),
1A1.n to 8B4.n (for virtual ports,
or All
Up, Down
Up, Down
autoConfig, uni30, uni31, uni40
iisp30, iisp31, pnni10, uniPvc,
nniPvc
Other, Network, User
Public, Private
0-6
SmartSwitch ATM Switch Reference Manual 2-221
PortConfig
Default
All
Up
Up
autoConfig
Other
Private
No default
