PnniNetworkNode

PnniNetworkNode
Use PnniNetworkNode to display all nodes within the PNNI hierarchy as seen from a logical node on the switch. The
logical node on the switch is viewed as the local node. The other nodes are viewed as remote nodes.
Operators
show
Parameters
Input Parameter
[Num]
Output Parameter
[Node Id]
If you give a specific [Num}, the
[Node Index]
[Peer Group Id]
[Node ATM Address]
[Rest. Transit]
[Complex Rep.]
2-182 SmartSwitch ATM Switch Reference Manual
Description
Index number of the remote node as assigned by
the console. Use the
show pnninetworknode
command to get a list of index numbers.
all
Description
Identifier of the remote node.
show pnninetworknode
An index into the set of nodal information associated with the remote node. This index
is needed since there may be multiple entries for nodal information from a specific
node.
Identifier of the peer group of the remote node.
ATM end system address of the remote node.
Whether or not the remote node is restricted to only allow support of SVCs originating
or terminating at its location. Possible values are: True and False. True indicates that
the transit capabilities are restricted; that is, transit connections are not allowed. False
indicates that transit connections are allowed. This parameter reflects the setting of the
restricted transit bit received in the nodal information PTSE of the originating node.
Whether or not the remote node uses the complex node representation. Possible values
are: True and False. True indicates the spokes and bypasses that make up the complex
node representation should be found in the pnniMapTable. This parameter reflects the
setting of the nodal representation bit received in the nodal information PTSE of the
remote node.
Value/Field Size
Positive integer or All
command displays the following additional fields.
Default
All
