PnniScopeMapping

PnniScopeMapping
Use PnniScopeMapping to set or display the mappings of membership and connection scope from UNI to PNNI terms.
The mappings are from the perspective of a logical node on the switch.
Operators
modify, show
Parameters
Input Parameter
[NodeIndex]
[LocalNetwork]
[LocalNetworkPlusOne]
[LocalNetworkPlusTwo]
[SiteMinusOne]
[IntraSite]
[SitePlusOne]
[OrganizationMinusOne]
[IntraOrganization]
2-200 SmartSwitch ATM Switch Reference Manual
Description
Identifier for a logical node on the switch.
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value localNetwork(1).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value localNetworkPlusOne(2).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value localNetworkPlusTwo(3).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value siteMinusOne(4).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value intraSite(5).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value sitePlusOne(6).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value organizationMinusOne(7).
Highest level of PNNI hierarchy (smallest
PNNI routing level) that lies within the UNI
scope value intraOrganization(8).
Value/Field Size
Positive integer
0-104
0-104
0-104
0-104
0-104
0-104
0-104
0-104
Default
1
96
96
96
80
80
72
72
64
