SmartSwitch 9000
9T122-24
User's Guide
9031206-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STH 24 STH-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cabletron Systems STH 24 STH-24

  • Page 1 SmartSwitch 9000 9T122-24 User’s Guide 9031206-02...
  • Page 3 Printed in the United States of America Order Number: 9031206-02 LANVIEW is a registered trademark, and SmartSwitch is a trademark of Cabletron Systems, Inc. CompuServe is a registered trademark of CompuServe, Inc. i960 microprocessor is a registered trademark of Intel Corp.
  • Page 4: Fcc Notice

    Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 5: Declaration Of Conformity

    ____________________________________________________ Title Rochester, NH, USA ____________________________________________________ Location ADDENDUM 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England...
  • Page 6 Notice...
  • Page 7: Table Of Contents

    Getting Help ... 1-4 Chapter 2 Installation Installing the MicroLAN Module ... 2-1 The Reset Switch ... 2-3 User-Accessible Components... 2-4 Setting the Module Card DIP Switch ... 2-5 Ring Speed ... 2-6 Multi-Ring Out Capability... 2-7 Chapter 3 Operation Bridging ... 3-2 Transparent Bridging...
  • Page 8 Contents...
  • Page 9: Chapter 1 Introduction

    Introduction The 9T122-24 MicroLAN™ Switch Module, shown in Figure 1-1, is a three port Token Ring bridge and router module. This module supports either one token ring with 24 HUB connections, or two separate Token Rings with 12 HUB connections, and an interface to the FNB backplane.
  • Page 10 A telnet session can be set up with the module to provide access to the Local Management screens. LANVIEW LEDs The 9T122-24 use LANVIEW – the Cabletron Systems built-in visual diagnostic and status monitoring system. With LANVIEW LEDs, you can quickly identify the device, port, and physical layer status at a glance.
  • Page 11 TOKEN RING 9T122-24 16 Mb Figure 1-1. The 9T122-24 MicroLAN Module Introduction...
  • Page 12: Related Manuals

    SmartSwitch 9000 9C300-1 Environmental Module User’s Guide SmartSwitch 9000 9C214-1 AC Power Supply User’s Guide SmartSwitch 9000 Local Management User’s Guide Getting Help For additional support related to this device or document, contact the Cabletron Systems Global Call Center: Phone Internet mail...
  • Page 13: Chapter 2 Installation

    Electrostatic Discharge (ESD). 6. Carefully examine the module, checking for damage. If any damage exists, DO NOT install the module. Contact Cabletron Systems Technical Support immediately. 7. Slide the module into a slot and lock down both the top and bottom plastic tabs, as shown in Figure 2-1.
  • Page 14 Installation Metal Back-Panel Warning: Ensure that the circuit card is between the card guides. Lock down the top and bottom plastic tabs at the same time, applying even pressure. Figure 2-1. Installing the MicroLAN Module Jack for ESD Wrist Strap Module Module Guides Plastic Tab...
  • Page 15: The Reset Switch

    The Reset Switch The Reset switch is located on the front panel, under the top plastic tab as shown in Figure 2-2. It serves two functions: • Pressing the reset switch twice within three seconds causes the processor (i960) to reset.
  • Page 16: User-Accessible Components

    User-Accessible Components Figure 2-3 shows the various components that are accessible to the user. These consist of an eight-position dip switch (explained in the next section), replaceable PROMs and sockets for RAM. These will be used for future upgrades. Figure 2-3. User Accessible Components...
  • Page 17: Setting The Module Card Dip Switch

    Installation Setting the Module Card DIP Switch An eight-switch DIP switch is located on the module card as shown in Figure 2-3 and in Figure 2-4. The function of the switches are listed in Table 2-1. 1 2 3 4 5 6 7 8...
  • Page 18: Ring Speed

    Clear Password Clear NVRAM Configuration Caution: Do not toggle Switch 8 unless you intend to reset the user configured passwords to their factory default settings. CAUTION Caution: Do not toggle Switch 7 unless you intend to reset the user parameters to the factory default settings.
  • Page 19: Multi-Ring Out Capability

    Multi-Ring Out Capability Any port of the module may be configured as a ring-out port through management software. In this configuration a stand-alone passive concentrator (such as an IBM 8228) may be added to the ring as shown in Figure 2-5. This allows for a star-wired network with the SmartSwitch 9000 at the center.
  • Page 20 Installation...
  • Page 21: Chapter 3 Operation

    Operation The 9T122-24 MicroLAN Module provides connectivity between the front panel Token Ring(s) and the FDDI rings on the backplane (FNB-1 or FNB-2). SmartSwitch 9000 modules connect to either the Internal Network Bus (INB) or the Flexible Network Bus (FNB) bus. The 9T122-24 module connects to the FNB bus.
  • Page 22: Bridging

    If the destination address of a packet resides on the bridge segment, the 9T122-24 does not forward across the Token Ring link. The second filtering process, the Cabletron Systems Special Filtering Database, provides an additional step in the filter/forward decision. Through Remote Management, you can define up to 10 additional filtering parameters for...
  • Page 23: Source Route Bridging

    Source Route Bridging Source Route Bridging operates by transmitting frames over a designated route. Unlike Transparent Bridging, all devices in a Source Route Bridged (SRB) network “know” the locations of other stations within the network. Using a portion of the MAC frame header known as the RIF (Routing Information Field), the source device determines the route for the frames it sends.
  • Page 24: Flexible Network Bus (Fnb)

    Operation Flexible Network Bus (FNB) The FNB consists of two dual FDDI networks, the FNB-1 and FNB-2, providing up to 400 Mbps of data bandwidth. These FDDI networks are 100% ANSI FDDI-compliant supporting SMT (version 7.3), MAC, PHY, and PMD standards. This allows the FNB to traverse multiple SmartSwitch 9000 hubs, or connect to any ANSI FDDI-compliant device, through standard A/B port connections, using the FDDI repeater module.
  • Page 25: System Diagnostic Controller

    System Diagnostic Controller This diagnostic controller is composed of a Z-80 microprocessor and its supporting logic. The diagnostic controller is designed to control the power-up sequencing of modules, monitor the 9T122-24 input and output power parameters, keep watch over the main host processor, as well as monitor the temperature and control the SMB LANVIEW diagnostic LED.
  • Page 26 Operation The i960 core provides the SNMP protocol stacks, as well as support for industry- standard MIBs. Additionally, Cabletron enterprise-extension MIBs are supported for each media type. Advanced management services, such as the Distributed LAN Monitor, RMON, telnet and network address to MAC address mapping, are also provided by the i960 core.
  • Page 27: Lanview Leds

    LANVIEW LEDs The front panel LANVIEW LEDs, shown in Figure 4-1, indicate the status of the module and may be used as an aid in troubleshooting. FNB Receive Token Ring Speed (16mb) TOKEN RING TOKEN RING 9T122-24 9T122-24 System Status FNB Transmit Token Ring Mac Transmit 16 Mb...
  • Page 28 LANVIEW LEDs The functions of the two System Status LEDs, System Management Bus (SMB) and the CPU, are listed in Table 4-1. LED Color Green Yellow Yellow/Green Red (Flashing) The functions of the FNB receive LED are listed in Table 4-2. LED Color Red (Flashing) Green...
  • Page 29 The functions of the Token Ring Mac receive LEDs are listed in Table 4-4. Table 4-4. Token Ring Receive LED LED Color Red (Flashing) Green Yellow (Flashing) Link, Activity (Flashing rate indicates rate of activity). The function of the Token Ring Mac transmit LEDs are listed in Table 4-5. Table 4-5.
  • Page 30 LANVIEW LEDs The function of the Token Ring speed LEDs is listed in Table 4-7. Table 4-7. Token Ring Speed LED Color State Yellow 16 Mbs 4 Mps...
  • Page 31: Chapter 5 Specifications

    Specifications Safety It is the responsibility of the person who sells the system to which the module will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions. CAUTION This equipment meets the safety requirements of: •...
  • Page 32: Physical

    Specifications Physical Dimensions: 35.0 D x 44.0 H x 3.0 W centimeters (13.8 D x 17.4 H x 1.2 W inches) Weight: Unit: Shipping: Electrical CPU: Shared DRAM Memory: Local DRAM Memory: Flash: Token Ring Interfaces: NVRAM: 1.36 kg. (3lb) 1.81 kg.
