Serial Data Configuration 2– PC to PC Communication
This configuration allows you to use PC applications and the RS-232 port of the Remote Module to connect
to a host computer at the office. Terminal access and digital phone functionality are provided across a single
ISDN B Channel. The other B channel can be used for an analog fax, phone, or modem.
PC running a COMM
application
PC running a COMM
application
Digital Phone
RS232
RS232
ISDN
Office Module Remote Module
BRI BRI
(Serial Data) (Serial Data)
RJ11
PBX
Analog Phone/Fax
Figure 6: Connections for PC Communication
EXTender 3000 System Administrator's Guide (Definity)
Data Communication Installation Topologies Page 65
