- Page 1 EXTender 4000 Universal Quick Installation Guide Quality is our job. Customer satisfaction is our mission! G-4000P-RXM Rev AF Nov 8, 2006...
- Page 2 Citel Technologies. Information in this publication is subject to change without notice. Citel Technologies may have patents or pending patents applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this publication.
-
Page 3: Table Of Contents
Networking ... 7 TCP/UDP... 7 Remote Location ... 7 Gateway Location ... 7 Power and Wiring... 7 Installation Components ... 8 Parts NOT Included with the EXTender 4000... 8 Typical Installation... 8 Location... 8 Compatible Telephones... 9 Connections ... 11 Power-Up... 12 Configuration using the Telephone Interface ... -
Page 4: Purpose Of This Document
Purpose of this Document This document provides instructions to install, configure, and troubleshoot the EXTender 4000 single client device. Safety Considerations IMPORTANT SAFETY INSTRUCTIONS • Do not install this product near water. Example: In a wet basement location. • Do not overload wall outlets, as this can result in the risk of fire or electrical shock. -
Page 5: Introduction
Ethernet network with other common data devices. The remote user can also connect a PC to the LAN through an RJ-45 Ethernet jack on the EXTender 4000, which acts as a hub. The voice and signaling traffic is transmitted over the LAN between the EXTender 4000 at the remote location and the PBXgateway at the central location. -
Page 6: Specifications
120V AC Adapter Environment Temperature 32° – 130°F (0° – 55°C) Relative Humidity 5 to 95% Dimensions 6.3 in. x 5.3 in. x 1.4 in. 160 mm x 135 mm x 34.5 mm Weight 300 g EXTender 4000 Universal Quick Installation Guide... -
Page 7: Prerequisites For Installation
Gateway Location The Gateway unit uses TCP/UDP port 2698. Power and Wiring The system is designed to operate at 120 VAC. Do not apply power to the EXTender 4000 until you are instructed to do so in the installation procedure. •... -
Page 8: Installation Components
Figure 1 shows a typical installation of the EXTender 4000. Location You can place the EXTender 4000 on any desktop, within 6 feet of an electrical outlet. Follow the Safety Considerations on page . 4 EXTender 4000 Universal Quick Installation Guide... -
Page 9: Compatible Telephones
EXTender. IX-8KTD and IX-8KTS IX-12KTD-2 and IX-12KTS-2 IX-24KTD and IX-24KTS IX-MKT EXTender 4000 Universal Quick Installation Guide Panasonic DBS Supported Add-on Modules VB-44310 EM24 - 24 Button Expansion Module VB-44320 DSS72 - 72 Button DSS/BLF Module Avaya Magix Digital... - Page 10 6424D+ (Definity) 5402 (Definity) 5420 (Definity) *NOTE: To select the proper PBX Type go to the Utilities menu in the UI and run the Setup Wizard again. EXTender 4000 Universal Quick Installation Guide Nortel Meridian M2006 * M2008 * M2216...
-
Page 11: Connections
Connections The EXTender 4000 requires connections A through D as shown in Figure 2. Letter Label Cable Type PHONE Cat 3 with RJ-11 connectors Cat 3/5/6 with a RJ-45 connectors Cat 3/5/6 with a RJ-45 connectors +12 VDC Power Supply Notes: * The PC port is a hub style Ethernet port and should connect only to an Ethernet station. -
Page 12: Power-Up
Power-Up 1. Once the EXTender 4000 is properly connected and powered it performs a series of self- diagnostic tests that are displayed as a series of LED flashes. The “Status” LED blinks for several seconds as the module initializes. 2. Once the power-up sequence has finished, the state of the LEDs should be:... -
Page 13: Configuration Using The Telephone Interface
Dynamic Host Configuration Protocol (DHCP) server. Set the IP Address - This is the IP address of the EXTender 4000 unit. All devices must have a unique IP address, if not using DHCP address mode. -
Page 14: Accessing The Phone Set Interface
(Moves down in chart.) No: Press to quit the current menu and return to the previous menu without making a change. (Some screens use this feature for enabling or disabling an option.) EXTender 4000 Universal Quick Installation Guide... -
Page 15: Menu Log, Continued
*: - to represent a period (.) when entering certain values, for example, an IP address. The figure below shows how to navigate through the telephone-set interface using the dial keys. Refer to this figure to use the following flowcharts. EXTender 4000 Universal Quick Installation Guide Figure 4: Menu Log... -
Page 16: Menu Structure
The following pages detail the menu structure for the telephone-set interface in a flowchart manner. Use the legend on the following page to help you navigate through the menus and access the required parameters. Shadowed Note: The parameters that you must enter are for easy identification in this flowchart. EXTender 4000 Universal Quick Installation Guide... -
Page 17: Main Legend
Ping IP Host 1: Prv 2: Ok 3: Nxt View System Info 1: Prv 2: Ok Restart Unit EXTender 4000 Universal Quick Installation Guide 3: Nxt 1: Prv 2: Ok 3: Nxt IP Menu 1: Prv 2: Ok 3: Nxt... -
Page 18: User Id Menu
1: Prv 2: Ok 3: Nxt Password 1: Prv 2: Ok 3: Nxt Gateway Address 1: Prv 2: Ok Auto Connect EXTender 4000 Universal Quick Installation Guide Enter User ID (Numeric values only) using the telephone key-pad. Commands: REDIAL to Accept Hold to Cancel “... -
Page 19: Ip Menu
DHCP Server not the Extender 4000 Unit. You may have to Note open a UPD Router Port EXTender 4000 Universal Quick Installation Guide To/From Previous Page 1: Prv 2: Ok 3: Nxt Address Mode If Mode is Static... -
Page 20: Admin Password Menu
Press the OK key (2). The display on the telephone indicates that the configuration is being saved. When the configuration is saved, you see the prompt “OK to Restart?” Press the OK (2) key to restart the remote module. EXTender 4000 Universal Quick Installation Guide Enter New Password Enter Password Again... -
Page 21: Configuration Using The Management Interface (Mi)
Configuration using the Management Interface (MI) Once the IP address is configured for the Extender 4000, you can use Telnet over the existing LAN connection to access the MI. This connection enables you to access the MI. The MI enables you to fully manage the i-Series Extender 4000 from your PC. - Page 22 9. Press the ←key to accept changes and go back to the Configuration Menu. 10. Press the ← k ey to the Save parameter. Press Enter to save changes to the active config (.rem) file. EXTender 4000 Universal Quick Installation Guide Figure 5:...
-
Page 23: Placing A Call
Auto-Connect – This is a Remote module option, which automatically connects remote users (tele- phones) when the EXTender 4000 is rebooted or brought on-line. (Eliminates the need to press “1” on the remote telephone.) Enable this feature for non-display telephones since you cannot see the “Press ‘1’ to Connect”... -
Page 24: Remote Telephone Messages
Displayed when the Switch unit has disconnected from the network device. Note: This message is not preceded by “Connect Error”. EXTender 4000 Universal Quick Installation Guide Action Wait until port is available or reset port on the PBXgateway and try to re-connect.
