Topping up the oil
Inspections after
the oil change
Maintenance manual
GMK5250L
•
Remove the drain plug (1).
•
Top up oil through the hole (2) until oil
comes out of the hole (1).
•
Replace the gasket and tighten the drain
plug (1) – torque 55 Nm (40.5 lbf ft).
•
Replace the gasket and tighten the drain
plug (2) – torque 55 Nm (40.5 lbf ft).
After changing oil, check for leakage:
•
Start the engine and let it idle in neutral N.
•
Check the screw plugs (1) to (4) for leakage.
3 302 744 en
Maintenance work on the carrier
7.6 Transmission
7 - 45
