How to Replace a ZS3-4 Memory
the Maintenance > Hardware screen of the BUI, and click on the right-arrow icon
controller. Then click DIMMs to locate the faulted component, indicated by the warning icon
.
Shut down the controller using one of the power-off methods described in
1.
to Power off the Controller" on page
Extend the controller from the rack as described in
2.
Controller from the Rack" on page
3. Remove the top cover as described in
Cover" on page
4. To locate the DIMM you want to service, press the Fault Remind Button on the
storage controller.
The following illustration shows the Fault remind button on the ZS3-4 controller.
