Oracle ZFS ZS3 Series Customer Service Manual page 126

How to Install Optional PCIe Slot Cards in Order
FIGURE 33
The LEDs located above each NET port are Link/Activity (left) and Speed (right) indicators for
each port as described in this table:
TABLE 28
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
ZS3-2 Cluster I/O Ports
Two cluster serial ports (0 and 1) and one Ethernet port provide communication between
two controllers to form a cluster configuration. For information about how to connect cables
to form a cluster, see the topic
Administration Guide, Release
FIGURE 34
126 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
ZS3-2 Controller Ethernet Ports
ZS3-2 Ethernet Port LEDs Description
EEE Terminology
100BASE-TX
1000BASE-T
10GBASE-T
"Cabling ZS3-2 Clusters" in Oracle ZFS Storage Appliance
2013.1.5.0.
ZS3-2 Controller Cluster I/O Ports: Serial 0, Serial 1, Ethernet
Speed LED Color Transfer Rate
Off 100 Mbits/sec
Amber 1000 Mbits/sec
Green 10000 Mbits/sec
