Servicing the ZS4-4 Controller
Slot
11
11
The legend describes the interconnect types and option codes shown in the Type column.
Legend for Interconnect Types and Options
A
B
C
D
ZS4-4 Connectors
This section describes ZS4-4 Ethernet ports, network management port, and serial management
port.
ZS4-4 Ethernet Ports
The ZS4-4 has four RJ-45 10-Gigabit Ethernet (10GbE) network connectors on the rear panel,
labeled NET 0, NET 1, NET 2, and NET 3 (bottom left to top right), as shown in the following
figure. Use these ports to connect the appliance to the network.
The LEDs located above the NET ports, labeled 2, 0, 3, 1 (left to right) are Link/Activity
indicators.
54 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Description
2-port 10Gb Ethernet Copper
NIC
16GB Dual Universal FC HBA
InfiniBand QDR QSFP+
- QSFP Direct Copper Cable Connect
- Optical Transceiver QSFP Short Range
40Gbs
Fibre Channel 16Gb SFP+
- Optical Transceiver SFP Short Range
16Gbs
GbE NIC Multi-mode Fiber SFP+
10GBase-SR/LR
- Optical Transceiver SFP Short Range
10Gbs
- Optical Transceiver SFP Long Range
10Gbs
GbE NIC UTP 10GBase-T
- Copper RJ-45 Unshielded Twisted Pair
Max Type
4 D
4 B
E Storage Array 4-port External SAS-2
Mini-SAS HD
- SFF-8644 Mini-SAS HD to Mini-SAS
Copper
F HDD 8-port Internal SAS-2 Mini-SAS
- SFF-8087 Mini-SAS to Mini-SAS
Copper
G Server Heartbeat 2-port RS-232 1-port
1GBase-T
-Copper RJ-45 Serial RS-232
-Copper RJ-45 Unshielded Twisted Pair
Note
Optional recommended front-
end
Optional FC target or initiator
(Backup)
