Figure Legend
Power supply unit 0 status LEDs OK: green Power
1
Supply Fail: amber AC OK: green
Power supply unit 0 AC inlet
2
Power supply unit 1 status LEDs OK: green Power
3
Supply Fail: amber AC OK: green
Power supply unit 1 AC inlet
4
System status LEDs Power: green Attention: amber
5
Locate: white
PCIe slots 0-4
6
Cluster card slot
7
ZS3-4 4x4 SAS-2 HBA
The 4x4 SAS-2 HBA, installed in the ZS3-4, provides connectivity to external DE2 and Sun
Disk Shelves. The HBA ports are numbered 3-0, top to bottom:
Servicing the ZS3-4 Controller
Figure Legend
Network (NET) 10/100/1000 ports: NET0-NET3
8
USB 2.0 ports
9
PCIe slots 5-9
10
Network management (NET MGT) port
11
Serial management (SER MGT) port
12
DB-15 video connector
13
