Oracle ZFS ZS3 Series Customer Service Manual page 173

7320 Clustered Controllers Configurations
TABLE 36
Slot Type
0 PCIe
0 PCIe
0 PCIe
0 PCIe
0 PCIe
1 PCIe
2 PCIe
7320 Chassis Overview
The Sun ZFS Storage 7320 consists of either a single storage controller or two storage
controllers in a high availability cluster configuration. Both the single and clustered
configuration supports one to six disk shelves.
The 7320 controller base configuration includes two CPUs, built-in 4 x 1Gb/s front-end GigE
ports, redundant power supplies, NIC options for expanded front-end support, tape backup,
InfiniBand, and dual port SAS HBA for storage expansion.
The CPUs are Intel Xeon 5600 series, 2.40GHz, 80W, with 4 core processors. The standard
memory configuration is 96GB, 6 x 8GB DDR3-1333 low voltage (LV) DIMMs per CPU.
Memory can be upgraded to 144GB using 9 x 8GB DDR3-1333 LV DIMMs per CPU (for a
total of 18 x 8GB for two CPUs). Earlier versions of the 7320 controller included 24GB (base),
48GB, or 72GB memory options. The clustered configuration simply uses two servers and a
cluster card in each server for a heartbeat connection between the servers.
All user-accessible storage is provided by one to six disk shelves that are external to the server
(s). RAID functions are managed by software. Solid state 18GB SAS-1 drives (7320 SAS-2) are
used for a high-performance write cache (known as LogZilla) or ZFS intent log (ZIL) devices,
Part Number Vendor Part
375-3617-01 Intel Niantic
375-3696-01 Mellanox
375-3606-03 MHJH29-XTC
375-3481-01 Intel
EXPI9404PT
371-4325-01 QLogic
542-0298-01 Sun
375-3609-03 Sun Thebe
Servicing the 7x20 Controller
Description Note
DP Optical Optional
10GE NIC Recommended
Front-end
InfiniBand HCA Optional
Recommended
Front-end
InfiniBand HCA Optional
Recommended
Front-end
QP Copper NIC Optional
Recommended
Front-end
8Gb DP FC Optional
HBA FC Target
or Initiator
(Backup)
Fishworks Cluster Base
Cluster Card 2 Configuration
External SAS Cluster Base
HBA Configuration
Servicing the Hardware 173
