Servicing the ZS4-4 Controller
1. Install additional 4x4 SAS-2 HBAs in slot 9, then slot 3.
2. Install InfiniBand CX3 HCAs into the first available client-option slot starting with slot 11,
then slot 8, slot 5, slot 1, slot 10, slot 3, slot 9.
3. Install 16Gb FC HBAs into the first available client-option slot starting with slot 11, then
slot 8, slot 5, slot 1, slot 10, slot 3, slot 9.
4. Install 10Gb Ethernet Optical NICs into the first available client-option slot starting with
slot 11, then slot 8, slot 5, slot 1, slot 10, slot 3, slot 9.
5. Install 10Gb Ethernet Copper NICs into the first available client-option slot starting with
slot 11, then slot 8, slot 5, slot 1, slot 10, slot 3, slot 9.
ZS4-4 PCIe Base and Optional Configurations
The following table describes the PCIe base and optional slot assignments for ZS4-4 standalone
and cluster configurations. PCIe slot numbering begins with slot 1.
See the legend for a description of the interconnect types and option codes shown in the Type
column.
Slot
1
1
1
1
2
3
3
3
3
3
4
52 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Description
2-port InfiniBand CX3 HCA
2-port 10Gb Ethernet Optical
NIC
2-port 10Gb Ethernet Copper
NIC
16GB Dual Universal FC HBA
8-port SAS-2 Internal HBA
4-port (4x4) SAS-2 External
HBA
2-port InfiniBand CX3 HCA
2-port 10Gb Ethernet Optical
NIC
2-port 10Gb Ethernet Copper
NIC
16GB Dual Universal FC HBA
Cluster Interface (second
generation)
Max Type
4 A
4 C
4 D
4 B
1 F
4 E
4 A
4 C
4 D
4 B
1 G
Note
Optional recommended front-
end
Optional recommended front-
end
Optional recommended front-
end
Optional FC target or initiator
(Backup)
Base configuration
Optional back-end
Optional recommended front-
end
Optional recommended front-
end
Optional recommended front-
end
Optional FC target or initiator
(Backup)
Base configuration
