Oracle ZFS ZS3 Series Customer Service Manual page 192

Servicing the 7x20 Controller
Slot
4
4
4
7120 Connectors
The serial management connector (SER MGT) is an RJ-45 port and provides a terminal
connection to the SP console.
FIGURE 60
The network management connector (NET MGT) is an RJ-45 port and provides an alternate
terminal interface to the SP console.
FIGURE 61
192 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Sun Part
Type
Number
PCIe 375-3481-01
PCIe 371-4325-01
PCIe 375-3609-03
7120 Controller Serial Management Port
7120 Controller Network Management Port
Vendor Part
Description
Number
Intel QP Copper NIC
EXPI9404PT
QLogic 8Gb DP FC
HBA
Sun Thebe 8P 6Gb/s SAS
(EXT) HBA
Note
Optional
Recommended
Front-end
Optional
FC Target
or Initiator
(Backup)
Additional
Optional Back-
end
