7120 Controller Rear Panel
FIGURE 55
Figure Legend
Power Supply Unit 1
1
Power Supply Unit 0
2
PCIe 0
3
PCIe 3
4
PCIe 1
5
7120 Physical Specifications
The 2U chassis form factor dimensions are as follows:
TABLE 45 7120 Controller Dimensions
Dimension
Height
Width
7120 Electrical Specifications
The following list shows the electrical specifications for the 7120. Note that the power
dissipation numbers listed are the maximum rated power numbers for the power supply. The
numbers are not a rating of the actual power consumption of the appliance.
Connectors
Two C13 connectors which work on 110-220v outlets
■
PCIe 4
6
Boot HDD 1
7
Boot HDD 0
8
Rear Panel System Status LEDs
9
Serial Management port
10
Measurement Dimension
87.6 mm/3.45 in Depth
436.8 mm/17.2 in Weight
Servicing the 7x20 Controller
Network Management port
11
Gbit Ethernet ports NET 0, 1, 2, 3
12
USB 2.0 ports (0, 1)
13
HD15 Video port
14
Measurement
765.25 mm/30.13 in
29.54 kg/65 lb
