Servicing the Disk Shelves
FIGURE 77
Figure Legend
DC power fail indicator
1
Fan fail indicator
2
AC power fail indicator
3
Power supply status indicator
4
Power on/off switch
5
The following figure shows power supply with fan module indicators for these disk shelves:
Sun Disk Shelf
■
246
Oracle ZFS Storage Appliance Customer Service Manual • February 2016
DE2 Disk Shelf Power Supply Indicators
Figure Legend
Universal power input connector
6
Power cord tie wrap
7
