How to Replace a ZS3-2 Power Supply
How to Replace a ZS3-2 Power Supply
Storage controllers are equipped with redundant hot-swappable power supplies. If a power
supply fails and you do not have a replacement, leave the failed power supply installed to
ensure proper air flow. A faulted power supply is indicated by an amber colored status LED.
Use the following procedure to replace a ZS3-2 power supply.
Gain access to the rear of the storage controller where the faulted power supply
1.
is located.
If a cable management arm (CMA) is installed, press and hold the CMA release
2.
tab and rotate the arm out of the way.
3. Disconnect the power cord from the faulted power supply.
4. Press the release tab to the left and pull on the handle.
