Oracle ZFS ZS3 Series Customer Service Manual page 168

Servicing the 7x20 Controller
Slot
5
5
5
5
6
6
6
6
6
6
7
7
7
7
7
7
168 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Mfg Part Number Description
375-3606-03 CX1 InfiniBand
HCA
7051223 2-port optical 10GE
NIC
371-4325-02 8Gb 2-port FC HBA
375-3696-01 CX2 InfiniBand
HCA
F375-3609-03 2-port SAS external
(7059331 for EU HBA
countries)
7054739 4-port copper NIC
371-4325-02 8Gb 2-port FC HBA
375-3606-03 CX1 InfiniBand
HCA
7051223 2-port optical 10GE
NIC
375-3696-01 CX2 InfiniBand
HCA
F375-3609-03 DP SAS external
(7059331 for EU HBA
countries)
7054739 4-port copper NIC
371-4325-02 8Gb 2-port FC HBA
375-3606-03 CX1 InfiniBand
HCA
7051223 2-port optical 10GE
NIC
375-3696-01 CX2 InfiniBand
HCA
Max Note
4 Optional
recommended front-
end
6 Optional
recommended front-
end
6 Optional FC target or
initiator (Backup)
4 Optional
recommended front-
end
6 Additional optional
back-end
6 Optional
recommended front-
end
6 Optional FC target or
initiator (Backup)
4 Optional
recommended front-
end
6 Optional
recommended front-
end
4 Optional
recommended front-
end
6 Additional optional
back-end
6 Optional
recommended front-
end
6 Optional FC target or
initiator (Backup)
4 Optional
recommended front-
end
6 Optional
recommended front-
end
4 Optional
recommended front-
end
