How to Replace a ZS4-4 HDD or SSD
Figure
5
ZS4-4 Attached Storage
The ZS4-4 single and cluster controller configurations allow up to 36 disk shelves, consisting
of up to six chains of one to six DE2-24 disk shelves; the Sun Disk Shelf is not supported. Any
combination of disk-only and Write flash disk shelves can be combined within the chain in any
order. For more information, see
Replacing the ZS4-4 Hardware
This section describes how to replace the following ZS4-4 hardware components:
"How to Replace a ZS4-4 HDD or SSD" on page 58
■
"How to Replace a ZS4-4 Power Supply" on page 60
■
"How to Replace a ZS4-4 Fan Module" on page 61
■
"How to Identify a Faulted ZS4-4 Memory Module" on page 63
■
"How to Replace a ZS4-4 DIMM" on page 64
■
"How to Replace a ZS4-4 Memory Riser Card" on page 66
■
"How to Replace a ZS4-4 PCIe Card" on page 68
■
"How to Replace a ZS4-4 Battery" on page 73
■
To become familiar with the replaceable parts of the system, see
Overview" on page
Be sure to read sections
"Prerequisites for Servicing Hardware" on page
How to Replace a ZS4-4 HDD or SSD
HDDs and SSDs are hot-swappable and can be removed and installed while the storage
controller is running without affecting other hardware capabilities. Use the following procedure
to replace a ZS4-4 HDD or SSD.
58 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Legend
Temperature sensor TS_ZONE1
(U4507)
Oracle ZFS Storage Appliance Cabling
44.
"Getting Started with Servicing the Hardware" on page 11
Figure Legend
11 Temperature sensor TS_ZONE0_A
(U4508)
"ZS4-4 Controller Hardware
39.
Guide.
and
