Oracle ZFS ZS3 Series Customer Service Manual page 88

Servicing the ZS3-4 Controller
Slot
6
6
6
6
6
6
7
7
7
7
7
7
7
7
8
9
9
88 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
Mfg Part Number Description
7070006 2-port 10Gb Ethernet
Copper NIC
375-3696-01 2-port InfiniBand
CX2 HCA
7070195 4-port 1Gb Ethernet
Copper UTP NIC
7051223 2-port 10Gb Ethernet
Optical NIC
371-4325-02 2-port 8Gb FC HBA
7023303 2-port 16Gb FC
HBA
7067091 4-port (4x4) external
HBA
7070006 2-port 10Gb Ethernet
Copper NIC
371-4325-02 2-port 8Gb FC HBA
375-3696-01 2-port InfiniBand
CX2 HCA
7051223 2-port 10Gb Ethernet
Optical NIC
7070195 4-port 1Gb Ethernet
Copper UTP NIC
371-4325-02 2-port 8Gb FC HBA
7023303 2-port 16Gb FC
HBA
7067091 4-port (4x4) SAS-2
external HBA
371-4325-02 2-port 8Gb FC HBA
7070006 2-port 10Gb Ethernet
Copper NIC
Max Note
4 Optional
recommended front-
end
4 Optional
recommended front-
end
4 Optional
recommended front-
end
6 Optional
recommended front-
end
4 Optional FC target or
initiator (backup)
4 Optional FC target or
initiator (backup)
4 Additional optional
back-end
4 Optional
recommended front-
end
4 Optional
recommended front-
end
4 Optional
recommended front-
end
6 Optional
recommended front-
end
4 Optional
recommended front-
end
4 Optional FC target or
initiator (backup)
4 Optional FC target or
initiator (backup)
4 Base configuration
4 Optional FC target or
initiator (backup)
4 Optional
recommended front-
end
