There are four RJ-45 Gigabit Ethernet connectors (NET0, NET1, NET2, NET3) located on
the motherboard that operate at 10/100/1000 Mbit/sec. These network interfaces must be
configured before use.
ZS3-4 Attached Storage
The ZS3-4 single and cluster controller configurations allow up to 36 disk shelves, consisting of
up to six chains of one to six disk shelves. Any combination of disk-only and Logzilla-capable
shelves may be combined within the chain in any order. You can also attach mixed disk shelf
types (DE2 family and legacy Sun Disk Shelves) behind the same controllers, but each chain
must contain only the same disk shelf type. Directly connecting different disk shelf types is
not supported. For more information, see
See also "Disk Shelf Hardware Overview" on page 234
diagrams.
Replacing the ZS3-4 Hardware
This section describes how to replace the following ZS3-4 hardware components.
"How to Replace a ZS3-4 HDD or SSD" on page 91
■
"How to Replace a ZS3-4 Fan Module" on page 93
■
"How to Replace a ZS3-4 Power Supply" on page 94
■
"How to Replace a ZS3-4 Memory" on page 97
■
"How to Replace a ZS3-4 PCIe Card or Riser" on page 105
■
"How to Replace a ZS3-4 Battery" on page 109
■
To become familiar with the replaceable parts of the system, see
Overview" on page 76.
Be sure to read sections
"Prerequisites for Servicing Hardware" on page
Oracle DE2-24s and Sun Disk Shelves can be used together with standalone and clustered
controllers after certain hardware modifications. Contact Oracle Service to update your
controllers for disk shelf interoperability.
How to Replace a ZS3-4 HDD or SSD
HDDs and SSDs are hot-swappable and can be removed and installed while the storage
controller is running without affecting other hardware capabilities. Use the following procedure
to replace a ZS3-4 HDD or SSD.
"Connecting to Attached Storage" on page
"Getting Started with Servicing the Hardware" on page 11
39.
How to Replace a ZS3-4 HDD or SSD
for component specifications and
"ZS3-4 Controller Hardware
Servicing the Hardware
266.
and
