Servicing the ZS4-4 Controller
FIGURE 7
Figure
1
2
3
4
5
6
50
Oracle ZFS Storage Appliance Customer Service Manual • February 2016
ZS4-4 CPU and Memory
Legend
Memory riser card P3/MR1
Memory riser card P3/MR0
Memory riser card P2/MR1
Memory riser card P2/MR0
Memory riser card P1/MR1
Memory riser card P1/MR0
7
Memory riser card P0/MR1
8
Memory riser card P0/MR0
9
CPU P3
10
CPU P2
11
CPU P1
12
CPU P0
