Figure Legend
Drive backplane
5
System lithium battery
6
ZS3-4 CPU and Memory
The ZS3-4 controller supports 16GB DDR3 DIMMs installed on all eight risers,
accommodating 1TB of memory.
ZS3-4 Controller DIMM Risers
FIGURE 18
Refer to the service label on the cover for DIMM placement information. On every memory
riser, slots D0, D2, D4, and D6 must be populated; optionally, slots D1, D3, D5, and D7 may
be populated as a group on
identical.
Figure Legend
11
installed memory risers. All DIMMs in the system must be
all
Servicing the ZS3-4 Controller
