Servicing the ZS3-2 Controller
Capacity
The ZS3-2 controller replaceable memory components and part numbers are listed below.
TABLE 25
Component
CPU
Memory
Memory
ZS3-2 NIC/HBA Options
The following table describes the NIC/HBA options for the ZS3-2 controller. See
Options" on page 123
TABLE 26
Mktg Part Number
SG-SAS6-INT-Z
SG-XPCIE2FC-QF8-Z
7103791
7101674
X1109A-Z
X4242A
7100477
7100488
X2129A
X5562A-Z
ZS3-2 PCIe Riser Configuration
The three risers are labeled Riser 1, Riser 2, and Riser 3. Though similar, the risers are not
interchangeable. Riser 1 installs at the left rear of the chassis, Riser 2 at the center rear, and
Riser 3 at the right rear of the chassis. Each riser can accommodate two PCIe cards:
122 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
CPU 0
D1, D3, D4, D6 (white)
ZS3-2 Controller Replaceable Memory Components
Description
Intel E5-2658, 2.1G, 8-
core
DIMM, 16GB,DDR3,
1600,2Rx4,1.35V
DIMM, 32GB,DDR3,
1066,4Rx4,1.35V
for slot allocations.
ZS3-2 Controller NIC/HBA Options
CPU 1
D1, D3, D4, D6 (white)
FRU/CRU Part Number
FRU 7019701
CRU 7041603
CRU 7055964
Description
8-port 6Gb/s SAS-2 internal HBA
2-port 8Gb FC HBA
4-port (4x4) SAS-2 6Gb/s external HBA
2-port 16Gb FC HBA
2-port 10GbE SFP+ NIC
2-port InfiniBand CX2 HCA
4-port 1Gb Ethernet Copper UTP NIC
2-port 10Gb Ethernet Copper Base-T NIC
XCVR 850NM, 1/10GPS, SFP, short reach
10GbE/1GbE SFP+ Transceiver, long reach
"ZS3-2 PCIe
