Riser 1 contains slots 1 and 4
■
Riser 2 contains slots 2 and 5
■
Riser 3 contains slots 3 and 6
■
ZS3-2 PCIe Options
The following table describes the supported PCIe configuration options for the ZS3-2
controller. Slots 1 and 2 are reserved for internal and external HBAs, as shown in the following
table. When adding PCIe cards, populate from higher order slots (6) first toward lower order
slots.
Any empty PCIe slots must have a filler panel installed.
Note -
ZS3-2 Controller PCIe Configuration Options
TABLE 27
Slot Mfg Part Number
1 7047852
2 7067091
3 7067091
3 7070195
3 371-4325-02
3 7023303
3 375-3696-01
3 7051223
3 7070006
4-6 7070195
4-6 371-4325-02
Description Max
8-port SAS-2 1
internal HBA
4-port (4x4) SAS-2 2
external HBA
4-port (4x4) SAS-2 2
external HBA
4-port 1Gb Ethernet 4
Copper UTP NIC
2-port 8Gb FC HBA 4
2-port 16Gb FC 4
HBA
2-port InfiniBand 4
CX2 HCA
2-port 10Gb Ethernet 4
Optical NIC
2-port 10Gb Ethernet 4
Copper Base-T NIC
4-port 1Gb Ethernet 4
Copper UTP NIC
2-port 8Gb FC HBA 4
Servicing the ZS3-2 Controller
Note
Base configuration
Base configuration
Second 4x4-port
SAS-2 external HBA
Optional
recommended front-
end
Optional FC target or
initiator (backup)
Optional FC target or
initiator (backup)
Optional
recommended front-
end
Optional
recommended front-
end
Optional
recommended front-
end
Optional
recommended front-
end
Optional FC target or
initiator (backup)
