Ethernet Ports
FIGURE 9
LED
OFF (1)
ON (0)
Blink
Speed is not indicated for the NET ports.
Note -
ZS4-4 Network Management Port
The network management connector (NET MGT), shown in the following figure, is an RJ-45
port and provides an alternate terminal interface to the service processor (SP) console.
Network Management Port
FIGURE 10
ZS4-4 Serial Management Port
The serial management connector (SER MGT), shown in the following figure, is an RJ-45 port
and provides a terminal connection to the SP console.
Servicing the ZS4-4 Controller
Status
No Link
Link and no activity
Link and activity
Servicing the Hardware 55
