1. Go to the Maintenance > Hardware screen.
2.
Click the right-arrow icon
fault icon.
3. Locate the fault icon in the lists of hardware components, and click it. The image
should be updated to show where that component is physically located.
4.
(Optional) Click the locator icon
The LED on the component will begin to flash.
How to Locate a Failed Component (CLI)
Use the following procedure to locate a failed component using the CLI.
1.
Go to the maintenance hardware context:
hostname:> maintenance hardware
2. List the appliance components:
hostname:maintenance hardware> list
NAME
chassis-000 hostname
chassis-001 000000000C faulted
Select the chassis and list its components:
3.
hostname:maintenance hardware> select chassis-001
hostname:maintenance chassis-001> list
4. Select the component type and show all available disks:
hostname:maintenance chassis-001> select disk
hostname:maintenance chassis-001 disk> show
Disks:
on the Storage System or Disk Shelf which has the
for that component, if the component has it.
STATE MODEL
ok Sun Storage 7320 unknown
J4410
disk
fan
psu
slot
How to Locate a Failed Component (CLI)
SERIAL
000000000C
