Configuring measured variables
Two channel version with two identical meas‐
ured variables
If the measured variables of measuring channel
1 and measuring channel 2 are chosen identi‐
cally, then the menu item
[Differential meas] appears in the
[Measurement] menu. The [Differential meas]
function is switched off "ex works". The function
[Differential meas] can be activated and the cal‐
[K1-K2] executed. The result of the cal‐
culation
culation is displayed in the main display 2 by
pressing the
key or
key. By pressing the
or
key again you jump back to the main
display 1. The limit value criteria for the
[Differential meas] can be set in the menu
[Limit values] .
80
