Function: Data logger
1. Use the arrow keys to select
[Error log book]
2. Press
3. Use the arrow keys to move the cursor
[Record]
to
4. Press
The activation symbol (tick)
ð
appears in the selection boxes.
Now all warnings and error mes‐
sages are recorded.
Reading messages
5. Use the arrow keys to move the cursor
[Read]
to
6. Press
This automatically removes the
ð
activation symbol. If you wish to
record further errors after
[Reading] , then it is necessary to
reactivate the
tick re-appears.
[error log book]
Deleting the
7. Use the arrow keys to move the cursor
[Delete]
to
8. Press
This will irrevocably delete the error
ð
log book file on the SD card.
Error log book
Entry
Warning 04 channel 2
The measuring channel is
not yet calibrated
Status coming
162
[Error log book] . The
32/32
Fig. 113: Reading the [Error log book]
Use the arrow keys to browse through the
entries in the error log book. Press
to the continuous display.
17.2.3 Using the
(optional)
The statuses of the digital inputs
The [Data log book] saves all measured
values, correction variables, control
variables and the status of the digital
inputs.
Data log book
Record
Read
Configure
Fig. 114: Configuring the [Data log book]
[Data log book] before you
First configure the
activate it. You can select which data is to be
recorded. All data is selected by default. You
can specify at what interval the data is to be
saved. For example, if one file is to be created
each per day, from 00.00 to 24.00. Then the file
name is = YYMMDD.CSV. You can also record
an endless file and give it a random name.
Data is always saved in CSV format. CSV
C omma- s eparated v alues. This
stands for
format can be, for example, read and edited
with MS Excel.
to return
[Data log book]
9.1.3.1
