Error
Error message text
34
The correction vari‐
able is faulty.
85
The external power
supply is faulty.
86
The communication
is faulty.
87
The connection to
the communication
module is faulty.
88
The connection to
the extension unit is
faulty.
99
A system error
exists.
Cause
One or more correction
variables have been
incorrectly entered
and/or the correction
variable has been
incorrectly recorded.
The external power
supply has been incor‐
rectly designed or is
faulty.
The connection ele‐
ments have been incor‐
rectly installed or are
faulty.
The connection cable
has slipped out of the
socket.
Connection problems
between the main and
extension unit.
System components
have failed.
Remedy
Check the correction variable and all
connected components.
Return the external power supply to its
correct working order.
Return the controller to the factory for
inspection.
Check the connection cable and
tighten.
Return the controller to the factory for
inspection.
Return the controller to the manufac‐
turer for inspection.
[Diagnostics]
171
