ProMinent DULCOMETER diaLog DACb Assembly And Operating Instruction page 136

[Control]
Setting the
Event controlled
Fig. 89: Event controlled
Description
Function
Signal source
Status
Switch off delay
Assignment
Time controlled
For use of a [Timer] function, a [Timer]
1 ... 10 must be switched on. The On
time and Off time must be specified
within the [Timer]. If the off time (e.g.
11:00) is before the on time (e.g.
12:00), then the [Timer] is activated
over two days.
136
Event
Function
Signal source
Status
Switch off delay
Assignment
Factory setting
Off
Digital input 2
Active opened
Off
Channel 1
3.5.1.1
On
Digital input 1
active opened
Off
Channel 1
A1478
Adjustment Options
On/Off
Digital input 2, digital input 5
Active opened, Active closed
0=Off...1800s
Dependent on device configura‐
tion, channel 1, channel 2, channel
1+2
Timer
Timer 1
Timer 2
Timer 3
Timer 4
Timer 5
Timer 6
Timer 7
Timer 8
Timer 9
Timer 10
Fig. 90: [Timer control] = [Timer]
3.5.2.1
A1479
