Assembly and installation
Fig. 12: Order number for the DAC control panel fitting kit (included with the scope of supply):
1041095.
I.
Control panel
1.
1 x foam rubber caulking strip ∅3
2.
Galvanised steel retaining brackets (6 off)
3.
Galvanised PT cutting screws (6 off)
Punched template
36
3
2
I.
1
A1179
