Assembly and installation
2
1
Fig. 11: Fitting the wall bracket
6.
Hook the bottom of the housing (1) into
the wall bracket
7.
Lightly press the housing at the top (2)
against the wall bracket
8.
Then check that the housing is hooked
in at the top and press down (3) until it
audibly engages
34
3
A0492
