ProMinent DULCOMETER diaLog DACb Assembly And Operating Instruction page 163

Configuration
Measured value channel 1
Temperature channel 1
Control variable channel 1
Measured value channel 2
Temperature channel 2
Control variable channel 2
Fig. 115: [Configuration] of the data log book
[Configuration] of the data log book
Configuration
Temperature channel 2
Control variable channel 2
Digital inputs
One file per day
Save interval
Fig. 116: [One file per day] checked
[One file per day] , then a new
If you uncheck
input option appears:
Configuration
Temperature channel 2
Control variable channel 2
Digital inputs
One file per day
File name
Save interval
9.1.4.1
9.1.4.13
[File name] .
9.1.4.13
Function: Data logger
Fig. 117: [One file per day] unchecked
1. If you wish to specify a file name, then
place the cursor on
press
[New] appears.
ð
2. Place the cursor on
You can now enter a random name
ð
with a maximum of 8 digits name
as well as the proposed
[DATALOG0.CSV] and/or set from
0 to 1 ... n.
The maximum file size is 2 GB
The maximum file size is 2 GB. The SD
card needs to be the same size.
Record
New
DATALOG0.CSV
Fig. 118: Check the file to write it to an existing
file, here [DATALOG0.CSV]
3. If you wish to attached measured data
to an existing file, then check this file
and the data will be written to this file
If the SD card is removed, then data can be
recorded for a maximum of 24 hours in the con‐
troller's internal memory with a storage interval
of 10 seconds. Around six times as long with an
interval of 60 seconds. When the SD card is re-
inserted into the controller, then the data from
[File name] and
[New] and press
9.1.3.4.1
