Assembly and installation
Terminal diagram for the extension unit (Channel 3) with assignment options
Extension unit, Channel 3, there can only be one main measured variable, e.g. pH, connected to a
unit. In addition, the mA signal of a magnetically inductive flow meter can be connected depending
on the ID code.
