AXP1440-C07 Shelf Installation
Phillips head screwdriver, #1

Phillips head screwdriver, #2

AdvancedTCA PEM Service Kit, PN 6706808A01 (shipped with your

AXP1440-C07)
Right-angle Cable Lug Kit, PN 6706808A01 (shipped with your AXP1440-C07)

5.3.2

Cable Information

These standard cables are available from SMART EC. Refer to the AXP1440-D data sheet
for ordering information.
RJ-45 front panel serial interface of the SAM1620-D

Adapter cable for the ADP1440-D front panel serial connection

5.3.3

Rack/Cabinet Cooling Guidelines

It is important to have sufficient open space at the front and rear of the shelf when installed
in a rack or cabinet. Depending on whether the enclosure has solid or vented doors will
determine the recommended open space required. Follow these guidelines for positioning
the shelf to allow for the optimal open space for the shelf air inlet and shelf air exhaust.
Do not obstruct the ventilation openings at the top, sides, and back of the shelf. Keep in
mind the following conditions when installing the shelf into a 600mm (23.62 inch) deep
rack. The physical dimensions in the next figure are in millimeters.
96 AXP1440-C07 Installation and Use (6806800V18A)
