Table 7-4
ADP1440-D LED
Critical Alarm (CRT)
Major Alarm (MAJ)
Minor Alarm (MIN)
Power (PWR)
The following table describes the LED types on the ADP1440-D and SAM1620-D. Refer to
Table 7-2 on page 142
ADP1440-D LED locations.
Table 7-5
LED
Alarm
Power
IS
OOS
HS
7.3.5.2

Hot Swap LED

The SAM1620-D provides a blue hot swap LED. This LED indicates when it is safe to
remove the SAM1620-D from a live shelf.
Table 7-6
State
Off
Blue
Long-blink
Short-blink
The software running on the shelf manager mezzanine is responsible for turning the LED
on/off using the GPIOs on the ShMC.
AXP1440-C07 Installation and Use (6806800V18A)
ADP1440-D LED Status Indicators
LED Color
Red
Red
Yellow
Green
for face plate LED locations and to
ADP1440-D and SAM1620-D LED Types
Type
Critical alarm (CRIT)
Major alarm (MAJ)
Minor alarm (MIN)
Power indicator
In Service
Out of Service
Hot swap ready
Hot Swap LED States
Condition
The SAM is not ready to be removed/disconnected from the shelf
The SAM is ready to be removed/disconnected from the shelf
The SAM is activating itself
Deactivation has been requested
Shelf Management Module
State State/Condition
On Active
On Active
On Active
On Power Present
Figure 7-3 on page 144
Location
Alarm Display Panel
Alarm Display Panel
SAM face plate
SAM face plate
SAM face plate
for the
