Platform Architecture

Figure 1-1 Top-Bottom-Back Plates View

These plates are compatible with Jonathon brand rails, so that the shelf can be
mounted on slide rails. See
The current configuration of this back plate limits the design to two rear transition
modules (RTMs) in the switch locations. The back plate may be configured for
additional RTMs. Contact your local SMART EC sales representative.
The locking features of shelf and blades are shown in the upcoming figures.
52
Top Plate
Bottom Plate
Figure 5-3 on page 99
AXP1440-C07 Installation and Use (6806800V18A)
Platform Architecture
.
Back Plate
