Site Preparation
When installing additional blades or modules, make sure that the power
consumption of all installed modules does not exceed the system's maximum power
dissipation.
3.3

Dimensions and Weight

The table below lists the dimensions and weight of the shelf and system components.
Table 3-4
Component
Shelf (base integrated platform)
Base platform: two PEMS, two SAMS,
backplane, upper and lower fan trays, ADP
board, and riser board. No payload blades.
PEM
Upper Fan Tray Module
Lower Fan Tray Module
ATCA-F140-D
RTM-ATCA-F140-D
3.3.1

Mounting Options

You can operate the AXP1440-C07 on your desk or you can install it in a standard 19" rack.
The AXP1440-C07 has additional rail mounting capability. The top and bottom plates
are compatible with the rail systems of Jonathon Company. See
. For hole spacing and configuration, please contact your local SMART EC sales
99
representative.
84
Dimensions and Weight of Shelf and Components
Dimensions
w x h x d
483 x 599 x 527mm
(19.05 x 23.60 x 20.75
inches)
164 x 73 x 155mm
(6.5 x 2.9 x 6.1 inches)
491 x 87 x 227mm
(19.3 x 3.4 x 8.9 inches)
491 x 119 x 331mm
(19.3 x 4.7 x 13 inches)
30 x 351 x 328mm
(1.2 x 13.8 x 12.9 inches)
30 x 351 x 120mm
(1.2 x 13.8 x 4.7 inches)
AXP1440-C07 Installation and Use (6806800V18A)
Site Preparation
Weight
(approximate)
49.4 kg
(109 lbs)
1.7 kg
(3.8 lbs)
4.1 kg
(9.1 lbs)
6.2 kg
(13.7 lbs)
2.9 kg
(6.3 lbs)
0.8 kg
(1.7 lbs)
Figure 5-3 on page
