2.7

IEEE802.3ap/IEEE802.3ba

The AXP1440-C07 backplane is designed to support 10G and 40G traffic through
10GBASE and 10GBASE-KR4.
2.8

Fan Tray Modules

The AXP1440-C07 supports two fan tray modules in a push/pull configuration. Each fan
tray module contains six dual-counter rotating fans.
The lower fan tray, LFT1440, is accessible from the front of the shelf and contains the
replaceable air filter.
The upper fan tray, UFT1440-D, is located in the rear of the shelf. It has an additional
backplane captive locking screw to help stabilize and secure the module and is accessible
from the front of the shelf. The screw is behind the front alarm panel display and must be
removed for access to the captive locking screw. Refer to
location of the captive locking screw.
Both fan tray modules have ejector handles that signal the IPM Sentry software for hot
swap.
The face plate of the upper and lower fan tray modules has the following status LEDs:
Table 2-7
LED
In Service (IS)
Out of Service (OOS) and Failure Red (default)
Hot Swap (HS)
AXP1440-C07 Installation and Use (6806800V18A)
LED Status Indicators
LED Color
Green
Blue
AXP1440-C07 Shelf Description
Figure 6-3 on page 134
State/Condition
Off: No service
Blink: activating
Glow Steady: Service available
Off: Service available
Blink: Deactivation requested
Glow Steady: No service
Off: is not ready to be removed
Blink: Deactivation requested
Glow Steady: is ready to remove
for the
73
