Shelf Management Module Installation And Removal; Figure 6-1 Sam1620-D Shelf Management Module - SMART Embedded Computing AXP1440-C07 Installation And Use Manual

FRU Installation
6.4 Shelf Management Module Installation and
Removal
The following sections describe the installation and removal procedures for the shelf
management module (SAM1620-D). For a detailed description of the SAM1620-D, refer to
Chapter 7 on page
The following figure shows the SAM1620-D shelf management module.

Figure 6-1 SAM1620-D Shelf Management Module

Damage of Circuits
Electrostatic discharge, incorrect blade installation and blade removal can damage
circuits or shorten their life.
Before touching the blade or electronic components, make sure that you are
working in an ESD-safe environment.
