AXP1440-C07 Shelf Description
Figure 2-1
shelf front and rear views.
Figure 2-1 Front Shelf View
Enhanced Top Plate
(for mounting heavy
duty rails)
Enhanced Bottom
Plate (for mounting
heavy duty rails)
64
and
show the location of the key components in the AXP1440-C07
Figure 2-2
Fan Tray
AXP1440-C07 Installation and Use (6806800V18A)
AXP1440-C07 Shelf Description
Alarm Display
Panel
Captive Chassis
Mounting Screws
(on both sides)
