Shelf Management Module
The default configuration of Ethernet channels is depicted in
Table 7-9
Function
SAM - SAM
Front Panel RJ-45 0.0.0.0
SAM to Hub

Table 7-10 Shelf Manager Dynamic Network IP Interfaces

Function
Dynamic/RMCP
The IP addresses defined in
active/backup switchover takes place, the addresses are reassigned to the
appropriate physical SAMs.
7.4.2.4

Configuring Front Panel Network Interface

To set front panel Ethernet and make it permanent over power cycle set the following U-
boot environment variables. This may be done in Linux or U-Boot. If done in U-Boot
saveenv must be executed to save the environment variables.
setenv ip1addr <IP address>
setenv gatewayip <gateway IP>
setenv enable_front_panel_ethernet y
saveenv
7.4.2.5

Configuring the RMCP Network Interface

To change the Remote Management Control Protocol (RMCP) network address that is
associated with the Active and Standby Shelf managers from the default values, use the
clia command on the Active shelf manager, where xxx.xxx.xxx.xxx indicates a sample
IP address.
clia setlanconfig 1 3 xxx.xxx.xxx.xxx
152
Shelf Manager Static Network IP Interfaces
IP SAM-A
192.168.25.101
192.168.24.101
IP Active SAM
192.168.24.11
Table 7-10
Ethernet
IP SAM-B
Device
192.168.25.100 ETH0
0.0.0.0 ETH1
192.168.24.100 ETH1.24
IP Backup Ethernet
SAM Device
192.168.24.10 ETH1.24:1
NOTICE
are relative to active/backup SAM. When
AXP1440-C07 Installation and Use (6806800V18A)
Shelf Management Module
and
Table 7-9 Table 7-10.
Default State
Enabled
Disabled
Enabled
Default State
Enabled
